CompX Fort 1-3/4" Disc Tumbler Cylinder Cabinet Cam Lock- Brass
CompX Fort 1-3/4" Disc Tumbler Cabinet Cam Lock – Brass
The CompX Fort 1-3/4" cam lock (part MFW23168B) is a disc tumbler cam lock with a brass finish, made for locksmiths and maintenance techs securing drawers and right- or left-hand cabinet doors. It mounts in a 3/4" hole and works with lipped/overlay construction (straight cam) or flush construction (formed cam).
The key turns 90° or 180°, clockwise or counterclockwise, and the lock ships with the parts to set it up for six different functions. FlexaCam is included.
Key Features:
- Disc tumbler, 1-3/4" cylinder length
- Fits a 3/4" mounting hole
- Max material thickness: 1-7/16"
- Straight cam for lipped/overlay construction; formed cam for flush construction
- 90° or 180° key rotation, clockwise or counterclockwise (six functions)
- Keys together with other CompX Fort flat-key locks on the K54G key blank
- Keying options: Keyed Different (KD), Keyed Alike #217 (KA217)
- Brass finish
Package Includes:
- 2 keys
- Trim washer and spur washer (for wood)
- Mounting nut
- 2 cams
- 90° and 180° stop cams
- Wonder washer
- 2 spline fillers
FAQs
Will this cam lock fit my overlay door?
Use the straight cam for lipped or overlay construction. For overlay installs, the front and frame together can't be thicker than the 1-3/4" cylinder length. Max material thickness is 1-7/16".
Can I key it to match my other CompX Fort locks?
Yes. It uses the K54G flat key blank and keys together with other CompX Fort flat-key locks. We carry it as Keyed Different (KD), Keyed Alike #217 (KA217).
Specifications
SKU#: COM-MFW23168B-217
weight: 0.01 lb
Download(s):
Vendor: Compx Security
Material:
Alternative Key:
Alternative Part Number(s):
Country of Origin:
Condition:
Key Type:
Pin Diameter:
Pins Per Pack:
Pin Length:
Function:
Programing Instructions :
Code Series :
Buttons:
Emergency Key Included :
Chip :
Reusable :
Battery:
Test Key:
Chipless Key :
Dimensions :
Special Marking (s) :
Replacement Brush:
Replacement Cutters(s) :
Power Supply :
Warranty :
Feature(s) :
Keyway:
Strike Plate:
Standards:
Thru Bolt:
Cross Bore:
Handing:
Latch:
Grade:
Keys:
Edge Bore:
Door Fitting:
Clutch Function:
Finish: US3
