Commercial Knob Privacy Grade 2 US32D 2 3/4" Locksets PHG
Feedback Help us improve our product images

Advantage EA Series | Grade 2 Privacy Knob | US32D

Write A Reviews
  • Vendor : PHG
  • SKU : PHG-102EA-BA-US32D
  • Weight : 1.0 lb
  • Latch : Mortise Backset Included
  • Strike Plate : ASA Strike 1-1/4" Width x 4-7/8" Height
  • Grade : 2 (Medium Duty)
  • Standards : ANSI Grade 2 ANSI/BHMA A156.2-2011 UL Listed 3 Hours Fire Rating UL10C/UBC 7-2(1997) Positive Pressure Rated ADA Compliant ANSI A117.1 Barrier Free Accessibility BHMA Certified Hurricane Hardware Certified NOA No. 15-0629.03 +/- 90 PSF Florida Building Code
See full product details
$ 26.07 - $ 26.07
$ 26.07
$ 26.07 - $ 26.07
$ 26.07
In Stock

Only 17 Advantage EA Series | Grade 2 Privacy Knob | US32D are available.

variantStock[3340549825] = 17;
$ 26.07 - $ 26.07
SubTotal : $ 26.07
$ 26.07 - $ 26.07
SubTotal : $ 26.07

Description

Advantage EA Series | Grade 2 Privacy Knob | US32D

Applications For offices, schools, hospitals, apartments, hotel/motel and other public buildings. Door Ranges 1-3/8” ~ 1-3/4” door thickness. Backset 2-3/4”(70 mm) standard Front 2-1/4” ~ 1-1/8”, adjustable for flat or beveled doors 1/8” in 2”. Strike Standard "T" strike (9106). 1-1/8" x 2-3/4" x 5/64" square corner. Latchbolt 1/2" throw stainless steel latch bolt. 2-3/4" backset - 1-1/8" x 2-1/4" faceplate mortise latch. 2-3/8" backset - 1" x 2-1/4" faceplate mortise latch. ANSI Grade II Standards Meets or exceeds requirement of BHMA/ANSI A156.2, 400,000 cycles. Exposed Trim Wrought brass or stainless steel. Pressure cast zinc lever.

Availability-7 days

Advantage EA Series | Grade 2 Privacy Knob | US32D Specifications

  • Weight : 1.0 lb
  • Latch : Mortise Backset Included
  • Strike Plate : ASA Strike 1-1/4" Width x 4-7/8" Height
  • Grade : 2 (Medium Duty)
  • Standards : ANSI Grade 2 ANSI/BHMA A156.2-2011 UL Listed 3 Hours Fire Rating UL10C/UBC 7-2(1997) Positive Pressure Rated ADA Compliant ANSI A117.1 Barrier Free Accessibility BHMA Certified Hurricane Hardware Certified NOA No. 15-0629.03 +/- 90 PSF Florida Building Code
  • Thru Bolt : Yes, Removeable
  • Warranty : Lifetime Mechanical Warranty
  • Cross Bore : 2-1/8"
  • Edge Bore : 1"
  • Handing : Universal, non-handing
  • Door Fitting : 1-3/8” ~ 2” door standard. Factory preset at 1-3/4”
  • Cylinder : Solid brass SC4 6-pin You can replace the cylinder with any K001 Cylinder
  • Clutch Function : Yes
  • Alternative Part Number(s) : 102EA-BA-US32D
  • Condition : New
  • Function : Privacy
  • Finish : US32D
